| Type | YY-80 | YY-100 | YH-100 | YH-120 | YP-150 | YP-200-A | YP-200 |
| Lamp head | |||||||
| Light output | 20W | 30W | 40W | 50W | 60W | 70W | 70W |
| LED chip | 120pcs | 140pcs | 140pcs(5050) | ||||
| Luminous flux | 3400lm | 4800lm | 6400lm | 8000lm | 9600lm | 12800lm | 12800lm |
| Beam angle | 150°*70° | 155°*55° | 160°*45° | ||||
| Lifespan | 50000hrs | ||||||
| IP Rating | IP65 | ||||||
| Working temperature | -20°C~60°C | ||||||
| Color temperature | 6000-7500K | ||||||
| CRI | Ra≥70 | ||||||
| SOLAR PANEL | |||||||
| Power | 60W | 70W | 100W | 120W | 150W | 150W | 200W |
| Voltage | 6V | 18V | |||||
| Solar cell efficiency | 17%-18% | 19%-20% | |||||
| Material | Polycrystalline silicon | Monocry stalline silicon | |||||
| BATTERY | |||||||
| Capacity | 192WH | 256WH | 320WH | 384WH | 576WH | 640WH | 640WH |
| Lighting time(full charged) | 5-7 rainy days | ||||||
| Lithium battery | LiFePO4 | ||||||
| INSTALLATION | |||||||
| Top diameter of pole | 60 mm | ||||||
| Mounting height | 7-8M | 8-10M | |||||
| Installation spacing | 20-40M | ||||||
