| MODEL | CAN BE SET | |
| MAIN INFO | ||
| Rated Voltage | 51.2V | |
| Rated Capacity | 200Ah | |
| Battery Power | 10.24kWh | |
| Battery Type | LFP | |
| Cycling Lifespan | ≥6000 (80%DOD,0.5C,25℃,70%EOL) | |
| Lifetime | 20 Years | |
| Max. Parallel Capacity | 16 | ✓ |
| CHARGE&DISCHRAGE | ||
| Max. Charging Voltage | 57.6V | ✓ |
| Over Discharging Voltage | 44.8V | ✓ |
| Max. Charging Current | 150A | ✓ |
| Peak Charging Current | 200A（3s) | ✓ |
| Max. Discharging Current | 200A | ✓ |
| Peak Discharging Current | 220A（3s) | ✓ |
| GENERAL | ||
| Weight | 87.66kg | |
| Dimension（L*W*H） | 555*166*926mm | |
| Communication | CAN / RS485 / USB / WiFi / Bluetooth | ✓ |
| Storage Condition | 6 months @25℃;3 months @35℃;1 months @45℃ | |
| Charging Temp. Range | 0～45℃（32~113℉) | |
| Discharging Temp. Range | -10～45℃（14~113℉) | |
| Cooling Method | Neutral Cooling | |
| Protection Grade | IP20 | |
| STANDARD | ||
| Transportation | UN38.3,MSDS | |
| Safety | EN55032,EN55024,EN61000-3-2,EN61000-3-3 |
