| Proven Li-ion battery management solutions | |
| PV CHARGE | |
| Solar Charge Type | MPPT |
| Maximum Output Power | 5000W |
| PV Charging Range | 0~80A |
| PV Operating Voltage Range | 120~500V |
| MPPT Voltage Range | 120~450V |
| AC CHARGE | |
| Maximum Charge Power | 3150W |
| AC Charging Current Range | 0~60A |
| Rated Input Voltage | 220/230Vac |
| Input Voltage Range | 90~280Vac |
| AC OUTPUT | |
| Rated Output Power | 5KW |
| Maximum Output Current | 30A |
| Frequency | 50Hz |
| Overload Current | 35A |
| BATTERY INVERTER OUTPUT | |
| Rated Output Power | 5KW |
| Maximum Peak Power | 10KVA |
| Power Factor | 1 |
| Rated Output Voltage (Vac) | 230Vac |
| Frequency | 50Hz |
| Auto Switch Period | ＜15ms |
| THD | ＜3% |
| BATTERY TECHNICAL SPECIFICATION | SunMate-B1605 |
| Number of batteries | 1 |
| Battery Energy | 5.12kWh |
| Battery Capacity | 100AH |
| Weight | 48.70kg |
| Dimension LxWxH | 710x450x192 |
| Battery Type | LiFePO4 |
| Battery Rated Voltage | 51.2V |
| Battery Working Voltage Range | 44.8~57.6V |
| Maximum Charging Current | 100A |
| Maximum Discharging Current | 100A |
| Parallel Quantity | 4 |
| Designed Life-span | ≥6000(80%DOD,0.5C,25℃,70%EOL) |
| GENERAL DATA | |
| Communication | RS485/CAN/WIFI |
| Storage time / temperature | 6 months @25℃;3 months @35℃;1 months @45℃; |
| Charging temperature range | 0~45℃ |
| Discharging temperature range | -10~45℃ |
| Operation Humidity | 5%~85% |
| Nominal Operation Altitude | ＜2000m |
| Cooling Mode | Force-Air Cooling |
| Noise | 60dB(A) |
| Ingress Protection Rating | IP20 |
| Recommended Operating Environment | Indoor |
| Installation Method | Horizontal |
| Certification | UN38.3,MSDS,CE |
| Weight(Inverter) | 27kg |
| Dimension L×W×H(Inverter) | 710×450×192 |
